MIL-DTL-17060G(SH)
APPENDIX F
(1) Shot number
(2) Range
(3) Operating mode
(4) Reference measurements
(5) Post-test measurements or conditions
f.
Survey findings, noting any damage and providing damage photographs.
g.
Modifications, if any, accomplished prior to or during test with applicable rationale, description, etc.
h.
Remarks.
i. Certification signature by test laboratory and witness and certification signature by Government activity as
to correctness of report.
TABLE F-III. Heavyweight shock machine test monitored performance.
Post-test
Range
Operating mode (on,
Reference
measurements 1/ or
Shot no.
measurements1/
off, open, closed, etc.)
conditions 2/
FSP
LFSP
1
40
110
2
30
80
3
25
65
4
20
50
NOTES:
1/
Volts, amperes, revolutions per minutes, pounds per square inch, alignment, clearances, bolting torques, etc.
2/
Yielding, cracking, short-circuiting, separating, unlatching, unbalanced, etc.
F.3.5 Post-shock test testing and inspection. The following information shall be included for all tests:
a. Identification of item being inspected through the use of such information as component name,
manufacturer, and drawing number.
b.
Type of shock test performed.
(1) Machine
(2) Platform
c.
Inspection and functional tests. Type of test accomplished and approval by the appropriate inspectors.
d.
Repairs which were necessary during tests.
e.
Condition of item being tested/inspected.
(1) Breakage
(2) Deformation
(3) Misalignment
(4) Unbalance
(5) Yielding
(6) Cracks
(7) Momentary malfunction
f.
Disposition of unit.
g.
Signatures certifying the report as correct.
(1) Test laboratory
