MIL-DTL-17060G(SH)
APPENDIX F
(2) Location
(3) Orientation
(4) Results
d.
Monitored performance. See table F-I for a sample tabulation format for required information.
(1) Blow number
(2) Drop feet
(3) Axis
(4) Operating mode
(5) Reference measurements
(6) Post-test measurements or corrections
e.
Survey findings, noting any damage and providing damage photographs.
f.
Modifications, if any, accomplished prior to or during test with applicable rationale, description, etc.
g. If witnessed by a designated Government representative, the report shall include signature of witness and
certification of test report.
h.
Certification of report by the test laboratory.
i.
Remarks.
TABLE F-I. Lightweight shock machine test monitored performance.
Operating mode
Post-test measurements
Blow
Reference
(on, off, open,
Drop feet
Axis
measurements 1/
or conditions 1/ 2/
number
closed, etc.)
1
1
2
3
3
5
4
1
5
3
6
5
7
1
8
3
9
5
NOTES:
1/
Volts, ampere, revolutions per minute, pounds per square inch, alignment, clearances, bolting torques, etc.
2/
Yielding, cracking, short-circuiting, separating, unlatching, unbalanced, etc.
F.3.3 Medium weight shock machine test. The following information shall be included for all medium weight
shock machine tests as defined by MIL-S-901:
a.
Type of test fixture. If nonstandard, included description and photographs.
b.
Total weight of anvil table (for vertical and inclined tests).
c.
Instrumentation.
(1) Gauge type
(2) Location
(3) Orientation
90
