MIL-PRF-62361E
AMERICAN NATIONAL STANDARDS INSTITUTE (ANSI)
ANSI/ASQC Z1.4
- Sampling Procedures and Tables for Inspections by
Attributes (DoD Adopted).
(Copies are available from: American National Standards Institute, 25 West 43rd Street,
New York, NY 10036 (or website: https://www.ansi.org/) or American Society for Quality, 600
North Plankinton Avenue, Milwaukee, WI 53203 (or website: https://www.asq.org/)
2.4 Order of precedence. In the event of a conflict between the text of this document and
the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has
been obtained.
3. REQUIREMENTS
3.1 First article. When specified (see 6.2), a sample shall be subjected to first article
inspection in accordance with 4.3.
3.2 Recycled, recovered, or environmentally preferable materials. Recycled, recovered,
or environmentally preferable materials should be used to the maximum extent possible provided
the material meets or exceeds all specified requirements and promotes economically
advantageous life cycle costs.
3.2.1 Dissimilar metals. Unless suitably protected against galvanic corrosion, dissimilar
metals shall not be placed in direct contact.
3.3 Operational needs.
3.3.1 Performance. Rated values cited in the following requirements shall be as
specified in table I. Except as otherwise specified herein, all performance shall be required at an
applied voltage of 24 + 0.5 volts direct current (V dc).
TABLE I. Rated performance.
Motor
Performance
Type I
Type II
Type III
Rated speed - rpm
2
8
6 1/
Rated torque - Newton meter (N-m)
0.11
0.08
1.13
Driving torque - N-m
0.35
0.16
N/A
Slipping torque - N-m
1.06
0.31
N/A
1/ At an applied voltage of 18 + 0.5, -0.0 V dc
